Solis 12KW IP66 L Plus Model Hybrid Inverter
The Solis 12kW 3-Phase Low Voltage Hybrid Inverter supports 24kW PV input, dual MPPT, lithium-ion battery integration, <10ms backup switchover, IP66 durability, and smart monitoring—perfect for large homes and small commercial solar systems.
₨525,000.00
100 in stock
Shipping
You have to pay Partial Payment for order confirmation
Estimated Shipping Time: 24 to 72 Hours
100% Original & Official Product
Solis 12kW 3-Phase LV | Hybrid Solar Inverter
The Solis 12kW 3-Phase Low Voltage Hybrid Inverter is designed for large residential and small commercial PV energy storage systems, combining high-capacity solar generation, advanced battery integration, and intelligent energy management. It provides a reliable, efficient, and scalable solution for users seeking energy independence.
With support for a maximum PV input of 24kW and a dual MPPT design (20A per channel), the inverter ensures precise energy harvesting from multiple PV arrays. Its battery compatibility (120–800V lithium-ion) allows for powerful 12kW charge/discharge capacity, making it ideal for both daily energy storage and backup.
Equipped with advanced safety features like anti-islanding, short-circuit, and overcurrent protection, plus an integrated DC switch, it guarantees safe and durable operation. The dual backup ports enable smart load prioritization for critical and non-critical appliances, with a rapid <10ms switchover time to keep power uninterrupted during grid outages.
For user convenience, the Solis 12kW features a 7.0-inch LCD display, Bluetooth connectivity, and optional app monitoring, providing full system visibility and remote control. Its IP66-rated enclosure ensures long-lasting durability in diverse environments, from residential rooftops to demanding commercial sites.
Key Highlights
Rated Power: 12kW, ideal for residential & small commercial PV systems
PV Input Capacity: Supports up to 24kW PV array
Dual MPPT: Two channels (20A each) for precise energy optimization
Battery Compatibility: Lithium-ion (120–800V), 12kW max charge/discharge
Backup Power: Dual ports for critical & non-critical loads, <10ms switchover
Advanced Protections: Anti-islanding, overcurrent, short-circuit, surge protection
User-Friendly Monitoring: 7” LCD, Bluetooth, app-based system management
Durable Design: IP66 enclosure for all-weather reliability
Scalability: Perfect for flexible, future-ready solar + storage setups
Key Specifications
| Specification | Details |
|---|---|
| Rated AC Output Power | 12,000 W (12 kW) |
| Max AC Apparent Power | 12,000 VA |
| Max DC (PV) Input Power | ~19.2 kW |
| Max Input Voltage (PV) | 550 V |
| MPPT Voltage Range | 80 – 520 V |
| Number of MPPTs | 3 (single-phase) / 2 (three-phase) |
| Start-up (Min) PV Voltage | ~100 V |
| Battery Voltage Range | ~40 – 60 V |
| Max Battery Charge / Discharge Current | ~250 A |
| Output Voltage (Grid side) | 220 / 230 V (single-phase) or 380 / 400 V (three-phase) |
| Grid Frequency | 50 / 60 Hz |
| Total Harmonic Distortion (THDi) | < 3% |
| Power Factor | >0.99 (adjustable 0.8 leading – 0.8 lagging) |
| Ingress Protection (IP Rating) | IP66 (outdoor rated) |
| Operating Temperature Range | –25 °C to +60 °C |
| Max Operating Altitude | ~4,000 m |
| Efficiency (Max) | ~97.6% |
| Backup / Overload Features | 200% overload (~10 sec) Dual backup ports (critical/non-critical) Auto switchover <4 ms |
| Display & Communication | 7″ LCD + Bluetooth / App; RS485; optional WiFi/LAN |
| Dimensions (W × H × D) | ~464 × 763 × 282 mm |
| Weight | ~48.5 kg |
